Faster cooling by 38%
Uniform cooling everywhere
Performance
Yield (Cool, Btu / hr)11942 Btu / hr
Yield (Heating, Btu / hr)13648 Btu / hr
Yield (Cool, Min - Max, Btu / hr)3310 ~ 13648 Btu / hr
Yield (Heating, Min - Max, Btu / hr)3310 ~ 19790 Btu / hr
Yield (Cooling, kW)3.5 kW
Performance (Heating, kW)4.0 kW
Yield (Cool, Min - Max, kW)0.97 ~ 4.00 kW
Performance (Heating, Min - Max, kW)0.97 ~ 5.80 kW
Energy efficiency
Cooling Efficiency Factor (EER) W / W3.61 W / W
Heating Efficiency Coefficient (COP) W / W3.81 W / W
Energy efficiency class in cooling mode (Classification)A ++
Energy efficiency class in cooling mode (W / W)6.7
Annual energy consumption (Cooling, kWh / year)183 kWh / annum
Energy efficient class in heating mode,A ++middle band (Rank)
Energy efficiency class in heating mode, at average temperature (W / W)4.6
Annual energy consumption (Heating, kWh / year)883 kWh / annum
Level of Noise
Sound Pressure Level (Indoor unit in high / low mode, dBA)40/16 dBA
Sound Pressure Level (High / Low Output Module, dBA)46 dBA
Sound Power Level (High Power Indoor Unit, dBA)58 dBA
Sound Power Level (High Power Outdoor, dBA)62 dBA
Electrical
Power supply (PV / Hz)Single Phase / 220-240 V / 50 Hz
Power Consumption (Cooling, W)970 W
Power Consumption (Heating, W)1050 W
Operating current (Cool, A)4.8 A
Operating current (Heating, A)5.0 A
Dimensions / Weight
Dimensions (Indoor unit, W x H x B, mm x mm x mm)826 x 261 x 261 mm
Dimensions (External unit, W x H x B, mm x mm x mm)790 x 285 x 545 mm
Net weight (Indoor unit, kg)10.2 kg
Net Weight (Outdoor Unit, kg)34.5 kg
Technical information
Tube length (max, m)15 m
Elevation Difference (Max, m)8 m
Tube Cross section (Liquid (ODxL))6.35 x 5
Tube Cross section (Gas (ODxL))9.52 x 5
Dehumidification yield (liters / hour)1.2 l / hr
Air circulation (Cool, m³ / min)12.0 ㎥ / min
Coolant (Type)Greenhouse Gas Fluoride (R410A, GWP = 2,088)
Coolant (Filling, kg)1.10 kg
Coolant (Filling, tCO2e)2.30 tCO2e
Operating Temperature (Cool, ℃)-10 ~ 46 ℃
Operating Temperature (Heating, ℃)-15 ~ 24 ℃
Outdoor Unit (Compressor Type)Twin BLDC
Outdoor unit (Anti-corrosion coating)Yes
Outdoor Unit (Multi Channel Capacitor)No
Air flow
Air Direction Control (Up / Down)Automatically
Air Direction Control (Left / Right)Automatically
Fan Speeds (Cooling / Heating)5/4
Air purification system
Triple filter "Neo"Yes
High Density Filters (Full HD)3 CareFilter (HD 60)
AntiallergiccoatingYes
Bacterial protectionYes
Auto CleanYes
Easy filterYes
Comfort
Smart Home (Wi-Fi)Yes
Filter cleaning indicatorYes
Existing temperature indicatorYes
Screen On / OffYes
Buzzer On / OffYes
24-hour timerYes
Auto switchYes
Auto restartYes
Operation settings
2 Step CoolingYes
Fast CoolYes
Comfort CoolYes
Sleep programYes
Single User ModeYes
Dehumidifier functionYes
| Attributes |
| Delivery | 3-4 Business Days |
| Features |
| Built-in display | Y |
| Dehumidifying capacity | 1.2 |
| Operating temperature (heating) (T-T) | -15 - 24 |
| Product colour | White |
| Type | Air conditioner indoor unit |
| Air conditioner functions | Cooling,Dehumidifying,Heating,Ventilating |
| Auto fan | Y |
| Cooling capacity (max) | 13648 |
| Cooling capacity (min) | 3310 |
| Cooling capacity in watts (nominal) | 3500 |
| Cooling energy efficiency (EER, W/W) | 3.61 |
| Heating capacity (max) | 19790 |
| Heating capacity (min) | 3310 |
| Heating capacity in watts (nominal) (Average heating season) | 4000 |
| Heating energy efficiency (COP, W/W) | 3.81 |
| Hose length (max) | 15 |
| Inverter technology | Y |
| Multi-split | N |
| Operating temperature (cooling) (T-T) | -10 - 46 |
| Refrigerating medium | R410A |
| Refrigerating medium weight | 1100 |
| Remotely operated | Y |
| Timer | Y |
| Timer duration (maximum) | 24 |
| Indoor unit |
| Indoor unit weight | 10200 |
| Indoor unit depth | 261 |
| Indoor unit height | 261 |
| Indoor unit noise level (high speed) | 40 |
| Indoor unit type | Wall-mountable |
| Indoor unit width | 826 |
| Indoor units quantity | 1 |
| Network |
| Wi-Fi | Y |
| Power |
| AC input frequency | 50 |
| AC input voltage | 220-240 |
| Current | 5 |
| Annual energy consumption (cooling) | 183 |
| Annual energy consumption (heating) (Average heating season) | 883 |
| Energy efficiency class (cooling) (old) | A++ |
| Energy efficiency class (heating) (Average heating season) | A++ |
| Power consumption (cooling) (max) | 970 |
| Power consumption (heating) (max) | 1050 |
