Wireless N Range Extender

DAP‑1360

The D-Link DAP-1360 Wireless N Range Extender can provide your wired network with wireless connectivity, or upgrade your existing wireless network and extend its coverage. Enjoy surfing the web, checking e-mail, and chatting with family and friends online, at faster speeds and from previously out-of-reach locations.

Network Standards

• 802.11n wireless LAN
• 802.11g wireless LAN
• 802.11b wireless LAN
• 802.3/802.3u 10BASE-T/100BASE-TX Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation

Device Interfaces • 802.11n/g/b wireless LAN • One 10/100BASE-TX Ethernet LAN port
Operating Frequency • 2.4 to 2.4835 GHz
Operating Channels • FCC: 11 • ETSI: 13
Radio & Modulation Schemes • DQPSK, DBPSK, CCK, OFDM

Functionality
Operating Modes

• Access Point
• Wireless Client
• Bridge
• Bridge with AP
• Repeater (Range Extender)
• WISP Client Router
• WISP Repeater

Antennas • Two 5 dBi Gain detachable omni-directional antennas
with RP-SMA connector

Security • 64/128-bit WEP data encryption
• WPA-PSK, WPA2-PSK
• WPA-EAP, WPA2-EAP
• TKIP, AES
• MAC address filtering
• SSID broadcast disable function
• WPS (Wi-Fi Protected Setup)

EIRP: 18.20 dBm
Device Management • Web-based management through Microsoft Internet
Explorer 6 or higher, Firefox 3.0 or higher, or other
Java-enabled browser
Status LEDs • Power
• Wireless
• Security
• LAN
